Technopet || Products || High Speed 2000 BPH Fully Automatic PET Bottle Blowing Machine

Specifications

Product Details

Production Max Mechanical Output BPH - 1800-2000 BPH
Bottle Ejection system and Method of bottle Transfer to infeed bay of Filling machine - Bottle automatically ejected from mold & drop down un- oriented & to be transferred to RFC
Type of Machine operation( Online/Off line) - Semi-Automatic with Auto Ejection System
Total Electrical Power sanction required to install machine - 45 HP Three phase supply
No of Bottle Cavity, Bottle Size / Volume - 2 Nos, 100 ml to 1000 ml
Bottle Neck size, Neck type - 28 mm, PCO/Three start/Short
Bottle Shape, Mould Locking System - Round and Square, Hydro-Pneumatic
Mould Opening, Mould Cavity Distance, Mould Thickness - 100 mm, 110 mm, 170 mm
LampsRating, Machine ConnectingLoad, Powerconsumption70% - 500 Watts, 13 KW, 09 Kw (12 HP)

Total Preform Holders, Max Heating Load, Motor & other Load - 12 KW, 1 KW, 13 KW
Preform Neck Cooling System - 360 Degree, Individual preform neck auard.
IR Heating station, IR Lamps/Station - 4 Nos, 6 Nos.
High Pressure Air, Chilling Water - 25 Bar-70 CFM-(25 HP), 2 Ton-50 LPM-10 deg. C
Air Drier HP, Air Filtration HP - 40 bar/80cfm, Pre, After and Micron
Voltage Servo Stabilizer, Weight of Machine Approx - 25 KVA-3 phase-+/-1%, 1000 Kgs
Length x Width x Height - Blow- 640 × 320 x 2220mm Oven-760 x 980 x 1330mm 1000Kgs
Men power required to operate 2 Numbers machine, Preform PCD in Oven - 2 Numbers, 38 mm
